Granule Extruder (Side-fed)

Granule Extruder (Side-fed)

Thanks to its one-touch operation feature, the extruder and auxiliary units can be quickly started from a single point.

  • PREXT 90
  • Screw Diameter: 90 mm
  • Screw L/D Ratio: 25 / 38 / 42 / 47
  • Screw Speed: 60 – 80 rpm
  • Heater Power: 25 kW
  • Gearbox Torque: 20 – 25 kNm
  • Motor Power: 45 – 55 kW
  • Capacity: 100 – 180 kg/h
  • PREXT 100
  • Screw Diameter: 100 mm
  • Screw L/D Ratio: 25 / 38 / 42 / 47
  • Screw Speed: 60 – 90 rpm
  • Heater Power: 30 kW
  • Gearbox Torque: 25 – 30 kNm
  • Motor Power: 55 – 75 kW
  • Capacity: 150 – 250 kg/h
  • PREXT 110
  • Screw Diameter: 110 mm
  • Screw L/D Ratio: 25 / 38 / 42 / 47
  • Screw Speed: 70 – 100 rpm
  • Heater Power: 30 kW
  • Gearbox Torque: 30 – 40 kNm
  • Motor Power: 75 – 90 kW
  • Capacity: 200 – 350 kg/h
  • PREXT 120
  • Screw Diameter: 120 mm
  • Screw L/D Ratio: 25 / 38 / 42 / 47
  • Screw Speed: 80 – 100 rpm
  • Heater Power: 40 kW
  • Gearbox Torque: 50 – 60 kNm
  • Motor Power: 90 – 110 kW
  • Capacity: 250 – 400 kg/h
  • PREXT 130
  • Screw Diameter: 130 mm
  • Screw L/D Ratio: 25 / 38 / 42 / 47
  • Screw Speed: 60 – 110 rpm
  • Heater Power: 40 kW
  • Gearbox Torque: 50 – 60 kNm
  • Motor Power: 110 – 132 kW
  • Capacity: 300 – 450 kg/h
  • PREXT 140
  • Screw Diameter: 140 mm
  • Screw L/D Ratio: 25 / 38 / 42 / 47
  • Screw Speed: 60 – 110 rpm
  • Heater Power: 40 kW
  • Gearbox Torque: 60 – 80 kNm
  • Motor Power: 110 + 132 kW
  • Capacity: 350 – 500 kg/h
  • PREXT 150
  • Screw Diameter: 150 mm
  • Screw L/D Ratio: 25 / 38 / 42 / 47
  • Screw Speed: 60 – 110 rpm
  • Heater Power: 50 kW
  • Gearbox Torque: 60 – 80 kNm
  • Motor Power: 132 – 160 kW
  • Capacity: 400 – 600 kg/h
  • PREXT 160
  • Screw Diameter: 160 mm
  • Screw L/D Ratio: 25 / 38 / 42 / 47
  • Screw Speed: 60 – 110 rpm
  • Heater Power: 65 kW
  • Gearbox Torque: 80 – 100 kNm
  • Motor Power: 200 – 250 kW
  • Capacity: 600 – 850 kg/h
  • PREXT 170
  • Screw Diameter: 170 mm
  • Screw L/D Ratio: 25 / 38 / 42 / 47
  • Screw Speed: 60 – 110 rpm
  • Heater Power: 80 kW
  • Gearbox Torque: 80 – 100 kNm
  • Motor Power: 250 – 315 kW
  • Capacity: 900 – 1,250 kg/h

Side-Fed Granule Extruder Systems
Side-fed granule extruder machines are designed especially for recycling lines requiring very high production continuity and complete independence without an operator. These systems feature an advanced automatic feeding and amperage regulation system that keeps machine performance under control without relying on manual adjustments.
Automatic Amperage Controlled Feeding System
Intelligent automation integrated into the side-fed module automatically adjusts the feed rate by monitoring the amperage values ​​of the extruder motor in real-time. This system makes machine capacity stable and efficient. • Eliminates the need for manual intervention by the operator. • The system extends the life of the motor by preventing overload. • Balanced feeding ensures that the extruder operates continuously at optimum performance. • Energy efficiency increases, and production lines can operate continuously for longer periods.
Intelligent PLC Control and Automation
Side-fed granule extruder machines are equipped with an advanced PLC control system and a touchscreen user interface. This allows operators to:
Define parameters specific to the plastic to be processed in advance and store them via the recipe system.

Settings such as heat, pressure, and feed rates required for each different type of plastic can be easily changed.
Thanks to the one-button start feature, the extruder and auxiliary units can be quickly operated from a single point. • Efficiency and Durability

  • This system not only increases production capacity but also:
  • Extends machine lifespan,
  • Reduces maintenance requirements,
  • Minimizes operating costs,
  • Eliminates operator errors.
